Application scope:SLE66R01High frequency electronic tags can be written 100000 times and can be encrypted. They are generally used for access cards, bus cards, small value stored consumer cards, subway tickets, electronic tickets, etc.
Product specification:
| model |
picture |
Antenna size |
Crosscut size |
Longitudinal spacing (antenna) |
Horizontal spacing (antenna) |
Coil width |
| HH-M002 |
|
52*15mm |
56*18mm |
10mm |
32mm |
47mm |
| HH-M003 |
|
Diameter:22mm |
Diameter:25mm |
8mm |
25mm |
47mm |
| HH-M004 |
|
22*35mm |
25X38mm/25X40mm |
8mm |
25mm |
47mm |
| HH-I002 |
|
45*45mm |
50*50mm |
8mm |
12mm |
57mm |
| HH-M007 |
|
32*32mm |
35*35mm |
8mm |
15mm |
47mm |
| HH-M008 |
|
11*26mm |
15*30mm |
20mm |
21mm |
47mm |
| HH-M009 | |
Diameter: 25mm | Diameter: 28/30mm | 15mm | 22mm | 37mm |
| HH-M010 |
|
Diameter:25mm |
Diameter:30/35/40/45mm |
Electronic performance:Chip: sle66r01
Frequency: 13.56MHz
Protocol: ISO 14443a
Capacity: 128 bytes
Package information:Surface substrate: coated paper /pet/ synthetic paper /pvc
Inner diameter of paper core: 76mm
Quantity per roll: 1000-5000 pieces (dry label)
1000-4000Film (self-adhesive label)
Winding direction: chip up
Quality inspection: 100% full inspection, and the bad standard has been replaced
Comprehensive performance:Working environment: -40 ℃ to 85 ℃
Storage environment: -5 ℃ to 30 ℃
Data validity: 100000 times
